VBOX Sport

Posted in Performance Meters and Lap Timers

A light-weight, portable data logger that can be used in any vehicle and environment to measure performance or lap times.

VBOX-Sport-iPhone-LapTimerApp

online-storeThe VBOX Sport can be used as a stand-alone logger or connected to an iOS device via Bluetooth.

Features

  • 20Hz GPS engine
  • Bluetooth interface to iPhone™ or iPad™
  • Over 6hr battery life
  • Internal rechargeable battery
  • Internal or external GPS antenna
  • Free Performance Test and Laptimer iPhone App available from Apple App Store
  • Robust, waterproof, lightweight enclosure
  • USB charging
  • SD card logging
  • Herbert Richter mounting system
  • Free data analysis software
  • Compatible with Harry's Lap Timer app, which is available for iOS and Android

RACELOGIC Apps

RACELOGIC have designed three dedicated iPhone apps: Performance Test, LapTimer and Diagnostics. Using the apps with VBOX Sport you can view GPS data that is being logged at 20 times per second and provides a level of accuracy currently unheard of with iPhone and iPad apps.

PerformanceTestApp-logo

VBOX Sport Performance Test

  • Accel / Decel
  • Speed
  • VMAX
  • 0-60, 0-100
  • 1/4 mile time
  • G-force
  • braking performance
  • zero to zero times
  • Free of charge

View in iTunes

LapTimerApp-logo

VBOX Sport LapTimer

  • Auto track selection
  • Predicted lap time
  • Current or maximum speed
  • Lap times / sector times
  • Custom circuit creation
  • Lap data analysis in CT
  • Range of config options
  • Designed for both iPhone and iPad
  • Free of charge

More info | View in iTunes

DiagnosticsApp-logo

VBOX Sport Diagnotics

  • Check health of the hardware
  • Check GPS data reception
  • Free of charge

View in iTunes



Partner Apps

VBOX Sport is also compatible with:

HarrysLapTimerApp-logo

Harry's LapTimer

  • Records all types of sensor data provided by your iPhone/iPod/iPad (or external sensors)
  • Harry's LapTimer Rookie, Petrolhead, and Grand Prix editions are available
  • Fully Automated GPS-based Lap Timing
  • Powerful Data Recording
  • Video Processor
  • Online database with more than 450 predefined tracks
  • $19.99

More info and screenshots
View in iTunes

RaceChrono

RaceChrono

  • Lap timer for circuit and point-to-point tracks
  • Gauge view of live data
  • Analysis mode with configurable graphs
  • Lap list with optimal lap time calculation
  • Exporting to CSV and NMEA
  • Bluetooth GPS support for superior accuracy over internal GPS
  • Support for VBOX Sport
  • Currently free

More info and screenshots in Google Play

 solostorm

SoloStorm

SoloStorm for Android v2.2+ devices allows you to log and analyze GPS, OBD-II, Sensor and Video data all on your smartphone or tablet.

  • Jog maps, data and video
  • Automated sectional analysis
  • Overlay video and data on the device
  • Compatible with both phones and tablets
  • Open licensing (run on as many devices as you want).

More Info


Interested in developing apps that connect to a VBOX Sport? More information on app development here.

Circuit Tools Analysis Software

Circuit Tools software is a data analysis package that comes with Video VBOX, VBOX Sport, DriftBox and PerformanceBox.

CT GPS Only-lb
The software is designed by racing drivers, for racing drivers, with none of the complexity normally associated with analysis software.

DB-sd-cardEasy to use

To analyse your track data, simply insert the SD card with your recorded data into your PC and select a file.

Huge track database

The software automatically detects the country, circuit and track configuration from a database of 400 circuits and uses the start/finish line information to separate the laps contained in your recorded file.

The fastest lap from your latest session is automatically chosen and displayed on the graph window. You can compare runs from this session, or from previous ones simply by clicking on the relevant lap time shown in the session window.

Delta-T-lbLap time difference channel

Time difference or 'Delta-T' is a very useful channel that shows the lap time difference between two different laps.

More about Circuit Tools Driver Analysis Software.

Performance Tools

This software allows you to analyse your vehicle's performance in a range of acceleration and braking tests.

To use the data logging, simply insert the 4GB SD card and drive. Once you have finished the test, remove the SD card and place it in a suitable reader.
Performance Box Tools Screenshots
The data is then read into the Performance Tools software, which you can download from the SD card supplied.

Add-On / Spare Products

H-Richter-mount
Suction Mount
The Herbert Richter suction mount can be installed as in-car dash moun, vent mount or as a tilt and swivel mount. Includes mounting plate.
Bar-mount
Handle Bar Mount
Easily fix the VBOX Sport onto the handle bar of your motorbike or bicycle. Includes mounting plate.
GPS-patch-antenna
GPS Antenna
Magentic patch antenna with 3M-MCX connector. Requires a ground plane.

Specs

Inputs and Outputs

VBS-inputs-outputs

GPS Specifications

Velocity

  • Accuracy: 0.1 Km/h
  • Units: Km/h or Mph
  • Update rate: 20 Hz
  • Minimum velocity: 0.1 Km/h
  • Maximum velocity: 1800 km/h
  • Resolution: 0.01 Km/h

Acceleration

  • Accuracy: 0.5 %
  • Maximum: 4 G
  • Resolution: 0.01 G

Heading

  • Resolution: 0.01° s
  • Accuracy: ±0.2° s

Position

  • 2D Position: ±5m 95% CEP *
  • Height: 5 Metres 95% CEP *

*95% CEP (Circle of Error Probable) means 95% of the time the position readings will fall within a circle of the stated radius

Recording and Storage

Recording options

  • Record only when moving (default)
  • Record start/stop button

SD Card Memory usage

  • 8.7 Megabytes/hour whilst logging

Environmental and Physical

  • Input Voltage: +5 Volts only
  • Power: 2.5 W max. (charging)
  • IP rating: IP65 (with connector bungs fitted), IP20 (without connector bungs fitted)
  • Size: 104.5mm x 72.8mm x 25.1mm
  • Weight: 130g
  • Storage temperature: -20°C to +60°C (max. limits), -20°C to +35°C for maximum battery life
  • Operating temperature:  -20°C to +55°C, 0°C to +45°C (whilst charging battery - charger will shut down outside this range)

Software

Apple software - available from the Apple App Store

  • VBOX Sport Performance Test
  • VBOX Sport LapTimer
  • VBOX Sport Diagnostics App

Windows software

  • Circuit Tools data analysis software

Support

  • Hardware: One Year
  • Software: Lifetime Support Contract: Valid for a minimum of 5 years from the date of purchase and limited to the original purchaser. Contract includes: telephone/ email technical support provided by local VBOX Distributor and firmware/ software upgrades (where applicable).
Download or print Datasheet.
